5086 aluminum plate has high strength capacity than 5052 and 5083 aluminum plate, but it is not strengthened by heat treatment, instead becoming stronger due to strain hardening or cold mechanical working of the material.3.0%-4.5% of magnesium is added to 5086 aluminum plate, which enable it to have high strength. Heat treatment does not strongly affect the strength, so 5086 aluminum plate can be readily welded and retain most of its mechanical strength. 5086 aluminum plate mainly has four tempers that are vastly used, including 5086-H, 5086-H32, 5086-H112 as well as 5086-H116.

lements	Si	Fe	Cu	Mn	Mg	Cr	Zn		Ti	Others		Al
Content	0.4	0.5	0.1	0.2-0.7	3.5-4.5	0.05-0.25	0.25		0.15	0.15		Remain
Alloy  Temper	Specified				Tensile strength			Yield strength			Elongation
	(mm)				(MPa)			(MPa)			(%)
5086-O (annealed)	Thickness 0.15-600     Width  30-2600     Length 500-16000				303			97			16
5086-H32					324			193			12
5086-H112					241			96			14
5086-H116					275			193			10

Features and Applications of 5086 Aluminum Sheet

5086 aluminum plate is primarily alloyed with magnesium. Forming characteristics are best with the alloy in the O temper. Machinability in the strain hardened tempers is relatively good. In the annealed (O temper) machining is difficult, but still can be accomplished. For its chemical contents, 5086 aluminum plate has good weld-ability and resistance to salt water correction, which making itself popular for vessel gangways and building boat. However, 5086 aluminum plate has a tendency to undergo stress correction cracking and is not used much in aircraft construction as a result.
